Volta – 12kW Single Phase Hybrid Inverter

Name: Volta - 12kW Single Phase Hybrid Inverter
SKU: VOLTA-LV-12
Availability: InStock

R28,393.20 excl VAT

The Volta Model 12 is a high-performance 12kW single-phase hybrid inverter designed to intelligently manage solar, battery, and grid or generator power. With advanced smart load management, a peak power output of 20kVA, and support for high-power PV modules, the Model 12 is a premium choice for both residential and commercial hybrid systems requiring fast switching, scalability, and efficiency.

SKU: VOLTA-LV-12 Category: HYBRID INVERTER Tag: VOLTA

Description

Nominal Output Power: 12kW
- Up to 20kVA peak power for 10 seconds
- 250A max charge/discharge current
- Supports UPS-level EPS switching <4ms
High PV Input & Oversizing:
- Supports up to 22kW PV input (200%)
- 2 MPPTs, 2 strings per MPPT
- Max PV voltage: 600V
- MPPT voltage range: 50–550V
- Max input current: 32A per MPPT
Battery Compatibility:
- Works with 48V lithium or lead-acid batteries
- Battery voltage range: 40–60V
- Battery temperature detection for safe operation Specifications
  - Max PV Input Power: 22,000Wp
  - MPPT Voltage Range: 50–550V
  - Max Battery Charge/Discharge Current: 250A
  - AC Output Voltage: 220/230/240V, 50/60Hz
  - AC Output Power: 12kW nominal / 20kVA peak (10s)
  - Max Efficiency: 97.6%
  - THDi (at rated power): <3%
  - Operating Temp Range: -25°C to +60°C
  - Dimensions: 652.5 × 462.5 × 259.8 mm
  - Weight: 37.4 kg
  - Protection Rating: IP65
  - Warranty: 5 Years
